Osram Flex Vfp1500-g3-827-05 4052899526372

Osram Flex VFP1500-G3-827-05 4052899526372 LEDVFP1500G3827

Osram Flex VFP1500-G3-827-05



VALUE Flex Protect 1500
VFP1500 -G3-827-05
LEDVFP1500G3827

Product family features:

Available with light color: Warm White, Cool White
Luminous flux: up to 1520 lm/m
Type of protection: IP66
High color consistency: 4 SDCM
Beam angle per module: 120Deg
Dimmable with suitable OPTOTRONIC control gears

Product family benefits:

Energy saving low-power flexible LED strip
Pre-wired LED strip, simple and quick plug-and-play installation
Good light output due to homogeneous LED distance and high color consistency
Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back
Easy installation with optional track system
Protection against the ingress of water according to IP66
Multi-cuttable LED strip with SLIMCONNECT system G2

Areas of application:

Wet or damp areas
General illumination
Hospitality
Display cabinet lighting
Signage
Architecture lighting
Wall integration
Suitable for outdoor use

Equipment / Accessories:

SLIMCONNECT system G2
Optional Track system
ELEMENT LED drivers
OPTOTRONIC LED drivers

Technical data:

EAN code: 4052899526372
Rated wattage: 57.50 W
Type of current: DC
Accidental reverse input voltage protection up to: 25 V
Nominal voltage: 24.0 V
Input voltage range: 23-25 V
Standard deviation of color matching: =4 sdcm
Total useful luminous flux: 7225 lm
Color temperature: 3000 K
Light color (designation): White
Light color LED: White
Rated lamp life time: 35000 h
Lumen main.fact.at end of nom. life time: 0.70
Nominal lamp life time : 35000 h
Number of switching cycles: 15000
Warm-up time (60 %): < 0.50 s
Rated beam angle (half peak value): 120.00 Deg
Beam angle: 120 Deg
Starting time: < 0.5 s
LED pitch: 14.28 mm
Product weight : 380.00 g
Cable cross-section, input side : 20AWG(0.519mm2)
Length - smallest unit: 100.0 mm
Length: 5000 mm
Width: 11.0 mm
Height: 4.0 mm
Cable length: 500.0 mm
Energy efficiency class: A+
Energy consumption: 64 kWh/1000h
Standards: Acc. to IEC 62471/Acc. to IEC 60598-1/Acc. to EN 60529/Acc. to EN 62031/Acc. to EN 55015/Acc. to EN 61547/CE
Type of protection: IP66
Temperature range in operation at Tc point: -25 - +80
Ambient temperature range: -25 - +55 DegC
Temperature range at storage: -30- +85 DegC
Performance temp. acc. to IEC 62717: 40 DegC
Number of LEDs per smallest unit: 7
Number of LEDs per meter: 70
Maximum operable length: 5000 mm
Dimmable: Yes
Lowest bending radius: 50 mm
With end piece: Yes
With connection set: Yes
Self-adhesive: Yes
Commodity Code: 9405403990
