Neutrik 5-Pin Female XLR Cable Connector NC5FXX

Neutrik XLR 5 Pin Female Cable XX Series NC5FXX CONC5FXX

The Neutrik NC5FXX is a professional 5-pin female XLR connector designed for DMX lighting, intercom systems, and balanced audio applications. Featuring a rugged diecast shell, it ensures reliable signal transmission in demanding environments. The XX Series design offers enhanced strain relief, and its silver-plated contacts provide optimal conductivity. Ideal for studio, stage, and broadcast use, this Neutrik 5-pin XLR connector is a top choice for professionals who require high-quality, secure connections.

XLR 5 Pin Female Cable XX Series

The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.

5 pole cable connector, female, nickel housing, silver contacts.Female contact incorporates a solder barrier to prevent solder from running into the contact mating area

Features & Benefits:

• Additional ground spring contacts for better shell ground continuity
• Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
• Boot with polyurethane gland gives high protection to cable bending stresses
• Coloured rings and boots available for coding or identification
• Sleek and ergonomic design - valuable and handy
• Rugged zinc die-cast shell, long lasting and dependable
• Internal thread on shell is well protected against any damage
• Branded with unique hologram - guarantees genuine and authentic Neutrik product

Technical Specifications:

• Rated current per contact: 7.5 A
• Rated voltage: 50 V
• Dielectric strength: 1.5 kV dc
• Cable O.D: 3.5 - 8.0 mm
• Wire size: max. 2.5 mm
• Wiring: Solder contacts
• Shell plating: Nickel

Priced per connector: available in any quantity

Packing information: Box quantity = 100

Coloured rings and boots available for coding or identification
