Neutrik Xlr 3 Pin Female Right Angle Cable Black Body Gold Pins Nc3frx-b

Neutrik XLR 3 Pin Female Right Angle Cable Black Body Gold Pins NC3FRX-B CONC3FRXB

3 pole right angle female cable connector

Black metal housing

Gold contacts

The RX Series is the right angle version of the XX cable connector series. The successor of the RC series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.
Extra slim right-angle connector with 5 selectable cable outlet positions
Female contact incorporates a solder barrier to prevent solder running into the contact mating area
Additional ground spring contacts for better shell ground continuity
Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster

Technical Specifications:

- Boot with polyurethane gland gives high protection to cable bending stresses
- Rated current per contact: 16 A
- Rated voltage: 50 V
- Cable O.D: 3.5 - 8.0 mm
- Wire size: max. 2.5 mm
- Wiring: Solder contacts
- Shell plating: Black chromium

Priced per connector: available in any quantity
Packing information: Box quantity = 50
Coloured rings and boots available for coding or identification
Manufacturer: Neutrik http://www.neutrik.co.uk/
