Neutrik Speakon 8 Pole Plug Cable Nl8fc Connector

Brand: Neutrik
Manufacturer Code: NL8FC
Product SKU: FAV-CONL8FC
Out of stock

Product Description

Neutrik SpeakON 8 Pole Plug Cable NL8FC CONL8FC

NL8FC
SpeakON 8 pole cable connector, latch lock, chuck type strain relief for cables 8 - 20 mm diameter, 30 A continuous per contact.

Technical Specifications:
- Rated current per contact: 30 A RMS continuous
- Rated current per contact: 40 A audio signal, duty cycle 50 %
- Dielectric strength: 4kV peak
- Rated voltage: 250 V (Insulation)
- Cable OD: 8 - 20 mm
- Wire size: 4 mm
- Wire size: 12 AWG
- Wiring: screw type terminals or soldering
- Priced per connector: available in any quantity
- Packing information: Box quantity = 50

Cable:
4-way-system: an eight-conductor cable on both ends wired to pins 1+/1-, 2+/2-, 3+/3-, 4+/4- of NL8FC
BI-Amp: a four-conductor cable on both ends wired to pins 1+/1-, 4+/4- of NL8FC
