Led Vfp1300-g2-865-05 Value High Power Ip66 65k 24v 4052899316683

Osram Led Vfp1300-g2-865-05 Value High Power Ip66 65k 24v 4052899316683 LEDVFP1300G2865

VFP 1300-865-5000

Product benefits

Energy saving low-power flexible LED strip
Easy installation with track system

Product features

Multiply cuttable LED strip with connectors (IP20)
Available with light colour Warm White, Cool White
Beam angle per module 120 Deg
Type of protection IP66
Dimmable

Areas of application

Hospitality
General illumination
Signage
Architecture lighting
Wall integration

Note

The lifetime of LED FLEX is reduced if the LEDs get too hot.
Heat management is best achieved with aluminium profiles.

In addition to acting as a heat sink, profiles provide protection and
can often enhance the appearance with use of a diffuser.
All high powered LED flex require heat management and this product
should be used with a suitable profile.

Technical Data

EAN: 4052899316683
Nominal voltage: 24 V
Power consumption: 83.5 W
Reverse Voltage: 25 V
Input voltage range 23-25 V
Colour temperature: 6500 K
Colour appearance: Daylight
Colour rendering index: 80 Ra
Size of smallest unit: 138 mm
Colour consistency: < 4 SCDM
Lifespan (@ Tc = 60 C): up to 35000 h
Light colour LED: White
Luminous efficacy: 84 lm/W
Beam angle: 120 Deg
Number of LEDs per module: 216
Number of LEDs per meter: 44
Luminous flux: 7000 lm
Luminous flux per m: 1400 lm
Nominal current: 3.48 A
Length: 5010 mm
Width: 11 mm
Height: 4.8 mm
Temperature range in operation: -10 +70 C
Dimmable: Yes
Standards: Acc. to IEC 62471/Acc. to EN 60529/Acc. to EN 62031/Acc. to IEC 60598-1/Acc. to EN 55015/Acc. to EN 61547/ROHS/VDE/CE
Acc. to IEC 62471/Acc. to IEC 60598-1/Acc. to EN 60529/Acc. to EN 62031/Acc. to EN 55015/Acc. to EN 61547/ROHS/VDE/CE
Commodity code: 940540399000

Manufacturers Website: www.osram.com/osram_com/products/led-technology/light-engines-and-modules/linear-led-modules-for-flexible-and-individualized-lighting-solutions/flexible-led-modules-for-private-and-semi-professional-applications/value-flex-1500
