Led Vf1500-g1-865-05 Value High Power Ip20 65k 24v 4052899316607

Osram Led Vf1500-g1-865-05 Value High Power Ip20 65k 24v 4052899316607 LEDVF1500G2865

VF 1500-865-5000

Product benefits

Energy saving low-power flexible LED strip
Easy installation with track system

Product features

Multiply cuttable LED strip with connectors (IP20)
Available with light colour Warm White, Cool White
Beam angle per module 120 Deg
Dimmable

Areas of application

Hospitality
General illumination
Signage
Architecture lighting
Wall integration
Display cabinet lighting

Note

The lifetime of LED FLEX is reduced if the LEDs get too hot.
Heat management is best achieved with aluminium profiles.

In addition to acting as a heat sink, profiles provide protection and
can often enhance the appearance with use of a diffuser.
All high powered LED flex require heat management and this product
should be used with a suitable profile.

Technical Data

EAN: 4052899316607
Nominal voltage: 24 V
Power consumption: 83.5 W
Reverse Voltage: 25 V
Input voltage range 23-25 V
Colour temperature: 6500 K
Colour appearance: Daylight
Colour rendering index: 80 Ra
Size of smallest unit: 138 mm
Colour consistency: < 4 SCDM
Lifespan (@ Tc = 60 C): up to 35000 h
Light colour LED: White
Luminous efficacy: 99 lm/W
Beam angle: 120 Deg
Number of LEDs per module: 216
Number of LEDs per meter: 44
Luminous flux: 8250 lm
Luminous flux per m: 1650 lm
Nominal current: 3.48 A
Length: 4990 mm
Width: 8 mm
Height: 1.8 mm
Temperature range in operation: -10 +60 C
Dimmable: Yes

Commodity code: 940540399000
Standards: Acc. to IEC 62471/Acc. to EN 60529/Acc. to EN 62031/Acc. to IEC 60598-1/Acc. to EN 55015/Acc. to EN 61547/ROHS/VDE/CE
Manufacturers Website: Acc. to IEC 62471/Acc. to IEC 60598-1/Acc. to EN 60529/Acc. to EN 62031/Acc. to EN 55015/Acc. to EN 61547/ROHS/VDE/CE
Manufacturers Website: www.osram.com/osram_com/products/led-technology/light-engines-and-modules/linear-led-modules-for-flexible-and-individualized-lighting-solutions/flexible-led-modules-for-private-and-semi-professional-applications/value-flex-1500
