32a Rack Mount Pdu With 8 X Neutrik Powercon Sockets Pdu16-pc32

Penn Elcom 32A Rack Mount PDU With 8 x Neutrik powerCon Sockets PDU16-PC32

2U 32 Amp AC Rack Mount PDU With 8 x Neutrik powerCon Sockets, Overload Protection & Power Monitoring

2U high Horizontal Mounting unit designed to provide versatile hook-up for the distribution of AC power within Multimedia Theatre & Touring rack applications.

• Circuit A:
• Main Input - C-FORM 240V 32A IP44 Panel Mount Appliance Inlet
• Protection - Illuminated Circuit Breaker overload protection between dual 16A sockets
• Output - C-FORM 240V 16A IP44 Panel Mount Appliance Outlet

• Circuit B:
• Output - 8 Neutrik powerCon sockets with a Maximum Combined Load 16A.
• Protection - Illuminated Circuit Breaker 16A overload protection
• LCD Monitor - LCD Power Monitor giving Voltage, Current , Power, Energy Levels & Overload Alarm.
• Earth Link - M4 Screw Terminal for Rack Grounding

• Nominal Voltage: 110V-240V
• Usable Voltages: 110V-240V full range
• Frequency: 50/60HZ full range
• Max. A/C Output: Current 16A
• Case Size: 88 x 140 x 430mm (O.A.483mm) / 3.46in x 5.5in x 16.92in
• Weight: 2.5kg (5.5lbs)

All components used in this conform to current RoHS, CE & UL certification - E&OE, (EMI:EN55022 (CISPR22) Class B; EN61000-3-2,3 EMS:EN61000-4-2,3,4,5,6,8,11; Light industry level, criteria A)
